Introduction
NUMERICAL
KEYPAD
Figure 1-1: The HandKey II
The HandReader has an integrated keypad for ID entry and reader programming.
It has two function keys (F1 and F2) that can be set to activate external devices
such as a doorbell or an automatic door. The
assist in data entry and programming.
Four different features assist the user with hand placement and read verification.
1. A light emitting diode (LED) hand placement display on the HandReader's
top panel assists users with hand placement on the platen.
2. A liquid crystal display (LCD) shows operational data and programming
menus.
Page 4
VERIFICATION
LIGHTS
LCD DISPLAY
HAND
PLACEMENT
DISPLAY
FUNCTION
KEYS
PLATEN AND GUIDE PINS
CLEAR ENTER
and keys
