5. Remove the screw at the back of the server system, next to the AC power input.
Save this screw. You will re-insert it later. See letter "A" in Figure 61.
6. Lift up slightly on the front of the power supply until it clears the foot at the bottom
of the chassis. See letter "B" in Figure 61.
7. Slide the power supply forward (see letter "C") and then lift it from the chassis.

Figure 61. Removing Power Supply from the Server System (SR1530SH)

®
Intel Server System SR1530SH/SR1530HSH User's Guide
A
B
C
B
AF002474
69
