HP T1936AA - Digital Sending Software Support Manual page 68

General tab page information
Each page (tab) in the Send-to-Printer component represents a
printer that can receive image files. The General tab defines the
default printer. Based on the file extension, narrow the routing further.
For example, add a tab and define a separate printer for TIFF images,
or define another printer for PDF files.
Configuring the Send-to-Printer component
Use the Send-to-Printer component to route images to printers that
are located anywhere on the network. This component provides
remote copying capabilities. See table 4-22 for more information.
Table 4-22. Send-to-printer configuration
Name
Activate
Printer name
Paper Size
Paper Source
Zoom/Pages per
Sheet
Orientation
Add
Remove
64 Chapter 4 - Configuration
Description
Select this field to activate the Send-to-Printer component
and send images to the printer.
Shows the name of the printer as it appears on the drop-
down list of configured printers on the server.
Indicates the size of the paper. The values that appear on
the drop-down list change in relation to the printer and
print driver.
Indicates the paper source based on available paper
sources on the printer driver.
Specifies the number of pages to appear on each printer
page.
Shows the print-media orientation for printing.
Adds a printer tab for a defined file extension. All files that
match the file extension are routed to the printer defined
on this tab rather than on the General tab.
Select a tab (other than the General tab) and click
Remove to delete the selected tab.
