How to Transition
from
HP ThinConnect
to HP ThinPro

Table of Contents:

Introduction ...........................................................................................2
.............................................................................................................3
Improved GUI Experience ................................................................................ 3
Add-on Support .............................................................................................. 3
Citrix Desktop Appliance (CDA) Mode .............................................................. 3
Things You Should Know Before Upgrading.............................................3
Stateless Architecture ...................................................................................... 4
User Group Brokering ..................................................................................... 4
Requirements .........................................................................................4
Hardware ....................................................................................................... 4
Management Software .................................................................................... 4
HP Thin Client Operating System...................................................................... 4
Creating a Master Image ........................................................................5
Download the Factory Image ........................................................................... 5
Create the Master Image on an HP t5145 Thin Client ........................................ 5
Deploying the Master Image-Single Deployment ....................................6
Capturing the Master Image ............................................................................ 6
Deploying the Master Image ............................................................................ 9
Deploying the Master Image-Mass Deployment .................................... 10
HP ThinConnect to HP ThinPro Using HPDM/PXE ............................................ 10
Setting Up the Master Thin Client ...................................................... 10

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T5145 - Thin Client - Tower and is the answer not in the manual?

Questions and answers

Related Manuals for HP T5145 - Thin Client - Tower

Summary of Contents for HP T5145 - Thin Client - Tower

  • Page 1: Table Of Contents

    How to Transition from HP ThinConnect to HP ThinPro Table of Contents: Introduction ...................2 Why Choose HP ThinPro over HP ThinConnect for the HP t5145 Thin Client? ......................3 Improved GUI Experience ................3 Add-on Support ....................3 Citrix Desktop Appliance (CDA) Mode .............. 3 Things You Should Know Before Upgrading…..........3 Stateless Architecture ..................

  • Page 2: Introduction

    Capturing the Master Image ............10 Setting Up the Target Thin Clients ............. 11 Deploying the Master Image ............12 HP ThinConnect to HP ThinPro Using Altiris ............. 14 Setting Up the Master Thin Client ............14 Capturing the Master Image ............14 Setting Up the Target Thin Clients .............

  • Page 3: Why Choose Hp Thinpro Over Hp Thinconnect For The Hp T5145 Thin Client

    Why Choose HP ThinPro over HP ThinConnect for the HP t5145 Thin Client? Improved GUI Experience The HP ThinPro GUI was built around a Control Center console to provide dashboard access to all user and administrative touch points. The initial view defaults to a Connection Manager layer with single click access to either a Control Panel or a System Information page.

  • Page 4: Stateless Architecture

    Stateless Architecture While HP ThinPro supports a convenient stateless mode of operation, it does not support the granularity found in HP ThinConnect. For example, HP ThinConnect enables the administrator to selectively choose which settings can be preserved locally and which settings are retained on an FTP repository. HP ThinPro takes a different approach, allowing administrators to choose either a fully stateless mode where settings are retained on an FTP repository, or a persistent mode (recommended) where settings are preserved locally.

  • Page 5: Creating A Master Image

    Creating a Master Image Download the Factory Image You can easily download the HP ThinPro factory image for t5145 to a USB drive www.hp.com key using the SoftPaq available on : HP ThinPro for HP t5145 Thin Client (128 MB). This SoftPaq provides a Win32 InstallShield wizard which will help you to turn your USB drive key into a bootable USB drive key that will install the ThinPro image onto your t5145.

  • Page 6: Deploying The Master Image-Single Deployment

    Deploying the Master Image—Single Deployment Capturing the Master Image 1. On the HP ThinPro image, switch to the Administrative Mode: a. Position your cursor in the screen background, right-click, and select Administrator/User Mode Switch. b. Type the Administrator password in the field and click OK. NOTE The default password is root.
  • Page 7 4. Under Which action do you want to do?, select make a copy of the HP ThinPro image, and then click Next.
  • Page 8 5. Under Where do you want to save the image?, select create a bootable USB flash drive, and then click Next.

  • Page 9: Deploying The Master Image

    6. Insert a USB drive key into the USB connector. Select the USB drive key, then click Finish. Deploying the Master Image Insert the USB drive key with the HP ThinPro master image into an HP t5145 thin client and turn on the thin client—the image is automatically installed.

  • Page 10: Deploying The Master Image-Mass Deployment

    Deploying the Master Image—Mass Deployment If you are deploying the new image to more than a few thin clients, remote deployment makes much more sense. Select from the following three procedures: HP ThinConnect to HP ThinPro Using HPDM/PXE • HP ThinConnect to HP ThinPro Using Altiris •...

  • Page 11: Setting Up The Target Thin Clients

    Setting Up the Target Thin Clients Enable Device Manager in all target thin clients. 1. From ThinConnect Settings Manager, click the Management tab > Device Manager. 2. In the HP Device Manager Configuration dialog, check Enable Device Manager and click OK. Click OK again when prompted. 3.

  • Page 12: Deploying The Master Image

    Deploying the Master Image 1. Create the job to deploy the new image: a. On the HP Device Manager server, open the Management Console. b. From the menu, click Tools > Repository Management. c. In the Select an element type to display field, select HP ThinPro Images. d.
  • Page 13 NOTE It may take a few minutes to add the element to the server. g. Click OK to add the element to the list, and then click Close. h. Click the Imaging tab. In the list, double-click _PXE Imaging to create a task from PXE Imaging templates.

  • Page 14: Hp Thinconnect To Hp Thinpro Using Altiris

    HP ThinConnect to HP ThinPro Using Altiris Setting Up the Master Thin Client 1. Change the boot order: a. Start up the thin client and press F10. b. Select Advanced BIOS Features > First Boot Device > Network. c. Press F10 to save the changes. Press Y to Save to CMOS and Exit. 2.

  • Page 15: Setting Up The Target Thin Clients

    Setting Up the Target Thin Clients 1. On the HP ThinConnect image, open the ThinConnect Settings Manager and click the Management tab. NOTE Altiris must be enabled on the target thin clients and the Altiris Client Agent should be set to start automatically with DHCP Altiris server port set to 190 scope option.

  • Page 16: Deploying The Master Image

    4. Create a script to change the boot order on the target thin clients: a. On the Altiris console, click View. Clear Show Thin Client View, if enabled. b. Click File > New, and select Job to create New Job in the Jobs console. c.
  • Page 17 2. Right-click the thin client and select Deploy Image. 3. Select the ThinPro image, click OK, and then click OK to confirm. The target thin clients will reboot automatically after the image is deployed. After rebooting, HP ThinConnect will be updated to HP ThinPro.

  • Page 18: Hp Thinconnect To Hp Thinpro Using Ftp Update

    HP ThinConnect to HP ThinPro Using FTP Update Setting Up the Master Thin Client No setup is required. Capturing the Master Image 1. On the HP ThinPro image, switch to the Administrative Mode: a. Position your cursor in the screen background, right-click, and select Administrator/User Mode Switch.
  • Page 19 6. Type the FTP server information in the fields. Example: Host : 10.1.1.1 Username : anonymous Password : anonymous Image directory :/linux/s2st0090/image/ Image file : HP00xxxxx.DD NOTE On the FTP server side, the image file extension must be upper case DD. Example: /linux/s2st0090/image/ HP00xxxxx.DD /linux/s2st0090/image/ HP00xxxxx.DD.md5 7.

  • Page 20: Setting Up The Target Thin Clients

    Setting Up the Target Thin Clients NOTE Because FTP update will check the image name format, change the HP ThinPro image name to the HP ThinConnect name format before updating. 1. On HP ThinConnect, in the HP ThinConnect Settings Manager on the Management tab, click Enable Automatic Update in the FTP area.

  • Page 21: Hp Thinpro To Hp Thinconnect Using Hpdm/Pxe

    HP ThinPro to HP ThinConnect Using HPDM/PXE 1. On the HP Device Manager server, open the Management Console. On the HP ThinPro tab and select the target thin client. 2. Click Tools > Repository Management, the click Add from local file to import the HP ThinConnect image to the HP Device Manager Repository and FTP Repository.

  • Page 22: Hp Thinpro To Hp Thinconnect Using Hpdm Without Pxe

    HP ThinPro to HP ThinConnect Using HPDM without 1. On the HP Device Manager server, open the Management Console. Find the thin client in the HP ThinPro tab and click to select it. 2. From the menu, click Tools > Repository Management. Import the HP ThinConnect image to the HP Device Manager Repository and FTP Repository.

  • Page 23: For More Information

    For More Information HP Device Manager 4.x User’s Guide © 2009 Hewlett-Packard Development Company, L.P. The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services.
