Click the Trace tool in the Tools panel.
1
In the document, click to select an area of color.
2
•
To add to the current selection, Shift-click additional areas.
•
To subtract from the current selection, Shift-click a selected area.
•
To deselect all areas, press Tab.
Click a selected area to open the Wand Options dialog box.
3
Choose an option:
4
•
Choose Trace Selection to trace the selection using the settings in the
Trace Tool dialog box.
•
Choose Convert Selection Edge to trace only the edges of the selected areas.
Using the Chart tool, you can create charts to visually display numeric data. You
create a chart by entering data and choosing display options. You can later edit the
data and change the display options to update the chart.
A FreeHand chart is a grouped series of objects that acts much like any other
group—you can enlarge, scale, rotate, and move it, and you can also edit
individual chart elements. Once you ungroup a chart, however, it becomes a
graphic and you can no longer edit the data, even if you regroup the chart.
Pictographs are graphics that replace the standard chart bars or lines with an
image. For example, you can represent a monetary value with a stack of coins or a
dairy value with a stack of cows.
Charts are created in grayscale. You can color them using various techniques.
Choose Window > Toolbars > Xtra Tools to display the Xtras toolbar.
1
Click the Chart tool in the Xtra toolbar.
2
Drag the pointer to set the initial size of the chart.
3
The Chart dialog box appears with the flashing cursor in the data entry text
4
box. The active cell is outlined in black.
To change the active cell, click a different cell or use the arrow keys.
