MACROMEDIA FREEHAND 10-USING FREEHAND Use Manual page 157

Choose the Pull Settings options.
4
•
Choose a Bend option from the drop-down list.
By Length lets you specify the length of the segment that will be affected, from
1 to 1000 pixels.
Between Points affects all of a path segment between its end points. A small s by
the pull cursor shows when this option is active.
Set the Pressure options if you are using a pressure-sensitive drawing tablet.
5
•
To activate the tablet's pressure-sensitive size adjustment capability, select Size.
•
To activate the tablet's pressure-sensitive length adjustment capability,
select Length.
Click OK.
6
Double-click the Freeform tool in the Tools panel.
1
In the Freeform Tool dialog box, select Push/Pull.
2
Click OK.
3
You can adjust the path two ways.
4
•
Click on the path and drag to pull the path. A small s beside the pointer
indicates that you are in Pull mode.
Pulling a path segment between points (top) and pulling a path of a specified
length (bottom)
