MACROMEDIA FREEHAND 10-USING FREEHAND Use Manual page 297

You can choose from 64 predefined pattern fills. You can also edit each pattern.
The inspector displays an editable version of the pattern on the left, and a preview
on the right that updates as you edit the pattern. Pattern fills print at one size on
PostScript output devices and do not scale with the object they fill.
For an example of the patterns available, see "Applying pattern strokes" on page 285.
In the Fill inspector, choose Pattern from the list.
1
Choose a color for the fill.
2
Click a pattern in the lower right corner of the inspector. Use the slider to scroll
3
through the available patterns.
In the Fill inspector, choose Pattern from the list.
1
Choose a color for the fill.
2
Choose a pattern, using the slider at the bottom of the inspector to scroll the
3
pattern list. The chosen pattern appears in the preview windows.
Drag or click pixel-by-pixel in the left preview. Clicking a pixel toggles between
4
black (opaque, in the selected color) and white (transparent).
Select Clear to remove a pattern from the preview window.
5
Click Invert to reverse pixel color—from color to white or from white to color.
6
PostScript applies a fill with a unique pattern and shape that you create in the
PostScript code entry text box. FreeHand sends the PostScript code to the
PostScript Interpreter in your printer's Raster Image Processor (RIP). If your code
is incorrect, you will receive a PostScript error message when printing.
PostScript fills do not appear on the monitor, but will appear when printed.
Note:
