MACROMEDIA FREEHAND 10-USING FREEHAND Use Manual page 170

Pictographs represent data visually, according to the type data shown. For
example, instead of a simple bar to represent a dollar amount, you can add a
pictograph of a dollar sign or stack of coins.
Select and copy the FreeHand graphic you'd like to use.
1
Use the Subselect tool to select a column in the series to which you'll apply
2
the pictograph.
Choose Xtras > Chart > Pictograph.
3
In the Pictograph dialog box, click Paste In to display the copied object in the
4
preview window.
To copy the selection in the Paste In window to the Clipboard, click Copy Out.
5
Choose how to fill the columns:
6
•
Select Repeating to fill the columns with repeating copies of the object. Partial
objects are used to represent incremental values.
•
Deselect Repeating to fill the column with one scaled object.
Click OK.
7
Select the column from which you want to remove the pictograph and choose
Xtras > Chart > Remove Pictograph.
