The installation procedure is just opposite to the removal procedure.
Installing/Removing a CF Card
Structure
Figure 6-15 Front view of CF card
Installing CF Card
Install the CF card following these steps:
Step 1: Push the ejector button into the slot completely, and make sure it only springs out with outside
force.
Step 2: Press the CF card into the slot in correct orientation, and make sure it only pops up with outside
force.
Figure 6-16 Press the CF card into the slot
Make sure the CF card with correct application program is properly installed in the slot; or, the system
cannot boot.
Removing CF Card
Remove the CF card following these steps:
Step 1: Check the CF card LED to make sure it is not blinking, and then proceed.
6-8
