Figure 6-12 Remove the power bracket and the power cord
2)
Remove the power module from the bracket
Remove the screws
Figure 6-13 Remove the screws fastening the power module and the bracket
Separate the power module from the bracket
Figure 6-14 Draw out the power module and separate it from the bracket
6-7
