H3C MSR 30-20 ROUTER Installation Manual page 61

Compiled date: Apr 09 2007, 08:52:28
CPU type
CPU L1 Cache
CPU Clock Speed : 533MHz
Memory Type
Memory Size
Memory Speed
BootRom Size
CPLD Version is
HardWare Version is
CF Card is Inserted, now is mounting...
cf:/ - Volume is OK
Mount CF Card OK!
CF Card Size:256MByte
Press Ctrl+B to enter extended boot menu...
Press Ctrl+B to enter extended boot menu...
The extended BootROM menu is referred to as main BootROM menu hereafter in this manual except
for special statement.
Press <Ctrl+B> when it displays "Press Ctrl+B to enter extended boot menu...". Then, the system
prompts:
Please input Boot ROM password:
You have three chances to provide the correct BootROM password (the initial setting is void). If you fail
to do that, you need to reboot the system. After you enter the correct password, the console screen
displays.
==================<EXTENDED-BOOTROM MENU>====================
| <1> Boot From CF Card
| <2> Enter Serial SubMenu
| <3> Enter Ethernet SubMenu
| <4> File Control
| <5> Modify Bootrom Password
| <6> Ignore System Configuration
| <7> Boot Rom Operation Menu
| <8> Clear Super Password
| <9> Device Operation
| <a> Reboot
=============================================================
Enter your choice(1-a):
The menu is defined as follows:
: MPC8349E
: 32KB
: DDR SDRAM
: 256MB
: 266MHz
: 4096KB
1.00
3.00
5-5
|
|
|
|
|
|
|
|
|
|
