More memory is required for the updated application program, maintaining a large routing table, or
processing tasks that consume large memory.
More memory is required for the upgraded application image, maintaining a large routing table, or
processing tasks that consume large memory.
The existing memory module is damaged.
Hold the memory module by its edge and avoid touching the components on its surface. An
improper operation might result in damage.
It is normal that you feel hard when removing the memory module, but do not overexert.
Use the memory module provided by our company. only. Otherwise, anomalies might occur to the
device.

Memory Module Structure

Figure 6-19 Memory module structure of the MSR 30-16
Figure 6-20 Memory module structure of the other modules

Memory Module Slot

Figure 6-21 Memory module slot of the MSR 30-16
