IPX/SPX Protocol Information
Information in this section of the Jetdirect configuration page is
described in Table
Table 9.7 IPX/SPX Configuration Information (1 of 2)
Message
STATUS:
PRIMARY FRAME
TYPE:
ENWW
9.7. For error messages, see
Description
Indicates the current IPX/SPX protocol status.
READY: Indicates the HP Jetdirect print server is awaiting
data over IPX/SPX.
DISABLED: Indicates that IPX/SPX was manually disabled.
INITIALIZING: Indicates that the print server is registering
the node address or name. An additional status message
may also be displayed.
An error code and message is displayed if the print server
is not ready. For more information, see
Specifies the frame type selection on the Jetdirect print
server.
AUTO SELECT: The print server automatically senses and
limits the frame type to the first one detected.
EN_8023: Limits the frame type to IPX over IEEE 802.3
frames. All others will be counted and discarded.
EN_II: Limits the frame type to IPX over Ethernet frames.
All others will be counted and discarded.
EN_8022: Limits the frame type to IPX over IEEE 802.2 with
IEEE 802.3 frames. All others will be counted and
discarded.
EN_SNAP: Limits the frame type to IPX over SNAP with
IEEE 802.3 frames. All others will be counted and
discarded.
TR_8022: Limits the frame type to IPX over IEEE 802.2 with
IEEE 802.5 frames. All others will be counted and
discarded.
TR_SNAP: Limits the frame type to IPX over SNAP with
IEEE 803.5 frames. All others will be counted and
discarded.
HP Jetdirect Configuration Page 223
Table 9.12.
Table 9.12.
