Table 4.4
TCP/IP Settings (2 of 4)
Item
Default IP
Send DHCP
requests
Host Name
IP Address
Subnet Mask
Default Gateway
Domain Name
ENWW
Description
Specifies the IP address to use when the print server is unable
to obtain an IP address from the network during a forced TCP/IP
reconfiguration (for example, when manually configured to use
BOOTP/DHCP).
DEFAULT_IP: sets the legacy default IP address 192.0.0.192.
AUTO_IP: sets a link-local IP address 169.254.x.x.
The initial setting is determined by the IP address obtained when
first powered on.
A checkbox is used to specify whether DHCP requests will be
periodically transmitted when a legacy default IP address
192.0.0.192 or link-local IP address 169.254.x.x has been
automatically assigned.
Clear the checkbox to disable DHCP requests.
Check the checkbox (default) to enable DHCP requests.
Specifies a readable IP name (the SNMP SysName object) for
the network device. The name must start with a letter and can
end in a letter or number, up to 32 ASCII characters.
Use this field to manually assign the Internet Protocol address
on the HP Jetdirect print server. The IP address is a four byte
(32-bit) address in the form "n.n.n.n", where 'n' is a number from
0 to 255.
An IP address uniquely identifies a node on a TCP/IP network.
Duplicate IP addresses on a TCP/IP network are not allowed. For
more information on IP addresses, see
If subnetting is used, use this field to manually assign a subnet
mask. A subnet mask is a 32-bit number that, when applied to
an IP address, determines which bits specify the network and
subnet, and which bits uniquely specify the node.
For more information on subnet masks, see
Identifies the IP address of a router or computer that is used to
connect to other networks or subnetworks.
Specifies the name of the Domain Name System (DNS) domain
that the HP Jetdirect print server resides in (for example,
support.hp.com). It does not include the host name; it is not the
Fully Qualified Domain Name (such as printer1.support.hp.com).
Appendix
Using the Embedded Web Server 120
