Initial Operation
Signal Quality
Using the Signal quality function, you can influence the measuring rate and the respective averaging. Averaging
with the Median function is specified by the preset. The subsequent moving averaging is specified by the Signal
quality function.
Individual material selection is possible in the Settings > Data recording > Material selection menu.
IMS5200-TH / IMS5200MP-TH
Averaging
Static
Median with 3 values
Moving with 128 values,
Measuring rate 0.2 kHz
Balanced
Median with 3 values,
Moving with 16 values,
Measuring rate 1 kHz
Dynamic
Median with 3 values,
Moving with 4 values,
Measuring rate 6 kHz
Description
In the signal quality section, you can switch be-
tween three basic settings (static, balanced and
dynamic). The reaction in the chart and system
configuration is immediately visible.
i
If the controller starts up with a user-defined
measurement setting (setup) the signal
quality cannot be changed.
