Initial Operation
Material Selection
The refractive index needs to be corrected in the controller for an exact thickness measurement. Only air may be pres-
ent between the sensor face and the measuring object (Material Infront); other media such as water or alcohol
are not permissible.
Material
Infront
Layer 1
Peak 1
You can edit or add to the material table. For a new material, a group refractive index is required.
Switch to the Settings > Data recording > Link to material table menu.
Assign the material according to the target used.
IMS5200-TH / IMS5200MP-TH
Switch to material selection by going to
Settings > Data recording.
Assign the material according to the
target used.
