MICRO-EPSILON interferoMETER IMS5200 Quick Manual page 10

LEDs Controller
Button Multifunction
The Multifunction button of the controller has multiple functions. It enables, e.g., to operate the light source.
The button is factory-set to the LED on/off feature.
Key function
1 / 2
There are two defined time intervals for pressing the button; each of these can be assigned a function. All time inter-
vals are indicated by the LEDs flashing/lighting up.
Function 1
Master value
LED on/off
0 2 sec
flashes off
slowly
IMS5200-TH / IMS5200MP-TH
Set / reset
Starts or stops the master measurement of the selected signals
master value
LED on/off Turns the light source on/off for the sensor
Inactive Key has no function
Function 2
5 sec 10 sec
flashes both
slowly off
Factory
setting
15 sec x min
green off both on
on
Key
lock
The Intensity and
Range LEDs indicate
time
the currently selected
function.
Multifunction Button
Actuation Time
Page 10
