Initial Operation
Presets, Measurement Configuration
Common measurement configurations (presets) for various targets are stored on the controller. This allows you to
quickly start with your individual measurement task. In a preset the basic features like peak or material selection and
calculation functions are already set.
When saving a modified preset, the web interface displays a dialog for entering a setup name. This prevents presets
from being overwritten by accident. Data output only starts when the associated interface is activated.
Preset
Overview possible presets
IMS5200-TH / IMS5200MP-TH
IMS5200 IMS5200MP
• •
• •
• •
The signal quality is set to Balanced at the
factory.
Go to the Home > Measurement config-
uration menu and start the Measurement
configuration.
Select a configuration.
Then, you can apply your own settings (setups).
Preset
•
possible preset
IMS5200 IMS5200MP
•
•
