Note:
Remove the breakaway tabs to access the DC
conduit openings.
Note:
Low voltage lines can be routed in the same
conduit as Ethernet if the wires are routed to the same
location.
Note:
Only round openings in the template are
functional. Square openings allow concrete flow.
Mounting Specifications - Walls
For wall mounted stations:
The wall must be smooth and plumb.
l
The wall must be designed or verified by a structural engineer for the weight of the Power Link 2000
l
and charging cables, per local regulations. See
21
Weights
for details.
