ChargePoint Power Block Design Manual page 10

Commercial Parking Arrangement
Stall parking: For stall parking, ChargePoint recommends
l
using perpendicular parking stalls that allow a vehicle to
enter either front-first or rear-first, to better accommodate
the varied locations of EV charge ports.
Note: While ChargePoint tests charging stations with a
majority of upcoming vehicles, ChargePoint cannot
guarantee the port locations of future vehicles and cannot
warrant the configurations proposed will work for all
vehicles.
Place single cable stations centred between two
l
parking spaces so that the cable runs down the
side of the stalls.
Island parking: For pull-through parking (petrol
l
station model), ChargePoint recommends placing
at least one charging station on each side of the
island. This avoids situations where the charging
station is on the opposite side of the vehicle from
the charge port.
5
