ChargePoint Power Block Design Manual page 14

Power Link 2000
The Power Link 2000 is a vertical enclosure that can be mounted on a pedestal, wall or overhead. Stations
can be configured with one or two charge cables, available in multiple lengths. The Power Link 2000 can
have different charging cable types (such as one CCS and one CHAdeMO) to offer flexibility, or it can have
the same cable type (in cases such as commercial fleets). The cables can both charge at the same time if
configured for simultaneous charging.
Charging cables can be either 4.5 (15 ft) or 7.6 m (25 ft) long.
The Power Link 2000 is available both with and without liquid cooled cables (LCC).
The Power Link 2000 can be configured with a Cable Management Kit (CMK), a rear mast with arms that
swing forward to extend cable reach.
Weights
See the table below for approximate Power Link 2000 weights.
Configuration or part
Power Link 2000 - pedestal with liquid cooled cable (LCC) backpack
(excludes charging cables)
Power Link 2000 - pedestal with non-liquid cooled cables
(excludes charging cables)
Power Link 2000 - overhead or wall mount
CMK - 2.4 m (8 ft)
Charging cable - 6.5 m (21 ft 4 in) - 250 A
Charging cable - 6.5 m (21 ft 4 in) - 350 A
Charging cable - 6.0 m (19 ft 8 in) - 500 A LCC
Charging cable - 7.9 m (25 ft 11 in) - 250 A
Charging cable - 7.9 m ((25 ft 11 in) - 350 A
Charging cable - 11 m (36 ft 1 in) - 250 A
Charging cable - 11 m (36 ft 1 in) - 350 A
Packaging excluded from weights listed above
9
Weight
200 kg
(441 lbs)
180 kg
(400 lbs)
120 kg
(265 lbs)
20 kg
(44 lbs)
16.39 kg
(36.24 lbs)
24.32 kg
(53.62 lbs)
18.8 kg
(41 1/2 lbs)
18.61 kg
41.03 lbs)
28.18 kg
(62.14 lbs)
23.54 kg
(52.9 lbs)
36.74
(81 lbs)
45 - 90 kg
(100-200 lbs)
