Power Block
Conservative stability specifications for the Power Block are listed below for the following design
scenarios:
1.
170 mph wind, high seismic, Class 3 Soil
2.
170 mph wind, high seismic, Class 4 Soil
3.
170 mph wind, high seismic, Class 5 Soil
4.
140 mph wind, lower seismic, Class 3 Soil
5.
140 mph wind, lower seismic, Class 4 Soil
6.
140 mph wind, lower seismic, Class 5 Soil
All scenarios assume:
Minimum concrete rating of 2500 PSI
l
An A1 anchor bolt embedment of 9 inches using M16 HAS-V-36 all-threaded rod (ASTM F1554 Gr. 36)
l
anchor rod with HIT-HY 200 adhesive
Design
B1,
Scenarios
Width
1
1753 mm
(69 in)
2
1753 mm
(69 in)
3
1524 mm
(60 in)
4
1524 mm
(60 in)
5
1524 mm
(60 in)
6
1524 mm
(60 in)
Note:
The Power Block must be centred within the designed stability area.
The concrete pad for the Power Block must either be designed to be site-specific or must meet the
specifications above. In some extreme conditions, a larger pad would be required. For sites with less
stringent seismic, soil or wind conditions, a smaller pad might be possible.
15
B2,
T,
Width
Thickness
1753 mm
457 mm
(69 in)
(18 in)
1753 mm
686 mm
(69 in)
(27 in)
1524 mm
457 mm
(60 in)
(18 in)
1524 mm
457 mm
(60 in)
(18 in)
1524 mm
457 mm
(60 in)
(18 in)
1524 mm
457 mm
(60 in)
(18 in)
#N1 @ S1" O.C.
Top Rebar
#4 @ 305 mm (12 in) O.C. #4 @ 305 mm (12 in) O.C.
#4 @ 152 mm (6 in) O.C.
#4 @ 305 mm (12 in) O.C. #4 @ 305 mm (12 in) O.C
#4 @ 305 mm (12 in) O.C. #4 @ 305 mm (12 in) O.C.
#4 @ 305 mm (12 in) O.C
#4 @ 305 mm (12 in) O.C
#N2 @ S2" O.C.
Bottom Rebar
#4 @ 152 mm (6 in) O.C.
#4 @ 305 mm (12 in) O.C
#4 @ 305 mm (12 in) O.C
