4. Rotate the picker so that the bar code scanner faces the rear of the library.
The location of the bar code scanner is shown in Figure 4.
Location of the
bar code scanner
Figure 4 The location of the bar code scanner.
5. Slide the picker along the transport tray to the front of the library (Figure 5).
Rack Mount Installation Guide
Figure 5 The picker is slid to the front of the library.
