Library Dimensions
A
Figure 2 Spectra 12K and 20K library dimensions.
Library
Spectra 12K
Spectra 20K
a. The library width will be 19.0 in. (48.26 cm) once the sliders are attached.
Rack Mount Installation Guide
B
a
A
B
24.5 in. (62.23 cm)
17.5 in. (44.5 cm)
24.5 in. (62.23 cm)
17.5 in. (44.5 cm)
6
C
C
31.0 in. (78.74 cm)
34.0 in. (86.36 cm)
