2. Slide the left slider into the left rail and push the library back into the rack.
3. Use the #2 Phillips screwdriver to attach the library to the rack. Use the
10-32 x 1/2-inch screws (six on the left side, four on the right side), and attach them
according to the numbered sequence illustrated below (Figure 46 and Figure 47).
Figure 46 The left side tightening sequence.
Rack Mount Installation Guide
Figure 45 The library in the rack.
4
6
9
10
8
2
1
Figure 47 The right side tightening sequence.
30
7
5
3
