Rack Mount Installation Guide

6. Use the adjustable wrench and a #2 Phillips screwdriver to attach the front and

back rails to each other with four countersink screws and bolts (Figure 43).

Figure 43 The front and back rails fastened together.

Caution:

Ensure that the nuts attaching the extension bracket to the rail

are tight. If the nuts are not tight, the rails will not support the

library's weight.
