Positioning the glass plate on the support
➢ Check the four slotted screws (1) for the correct distance between the
support and the screw head.
If the distance is too small, turn the screws slightly counterclockwise to
increase the distance.
➢ The tommy screw (2) must be removed before placing the glass plate on
the support.
➢ Position the glass plate over the four slotted screws (1) of the glass plate
carrier and insert it from above.
Inserting the glass plate
➢ Tighten the four slotted screws (1) and finally secure the glass plate with
the tommy screw (2) in the middle.
Remove glass plate
➢ Remove the tommy screw (2) from the center of the glass plate carrier.
➢ Lift the glass plate out of the slotted screws (1).
Important: Always hold the glass plate firmly with both hands due to its
heavy weight! Sometimes it is advisable to loosen the slotted screws (1)
slightly. This reduces the force required to lift the glass plate.
Connecting the touchscreen monitor
Risk of electric shock due to incorrect connection.
➢ Ensure that the mains socket is earthed in accordance with
local regulations.
Incorrect routing of the connection cables can cause tripping,
broken bones, bruises and crushing.
➢ Lay the connection cables so that no one can trip over
them.
To connect the touchscreen monitor, proceed as follows:
WARNING
CAUTION
Prepare setup
