Installation site
Installation site
Environmental conditions
When operating the scanner, make sure that the room is well ventilated to
ensure the operating conditions.
The installation site must be chosen so that
• the distance between the sides of the scanner and the wall is at least 100
mm,
• the distance between the back of the scanner and the wall is at least 0
mm,
• the distance to a door or room entrance is at least one meter.
Place the scanner on a level and stable base (at least four table legs). The
load-bearing capacity of the base must be suitable for the weight of the
scanner (at least 60 kg. / 133 lbs). The dimensions of the base must be
suitable for the footprint of the scanner (at least 90 cm x 180 cm / 36 x 71
inch).
