Ball
U14
AB12
U11
T11
AA11
G5
H6
J5
J6
K6
H5
J7
L6
M6
K7
G16
E18
G1
G2
G13
E11
U15
Y3
AB3
AA3
W3
V4
U5
W2
M2
M1
M3
M5
L2
M4
L3
K2
F12
E12
F13
F15
UM3359 - Rev 2
Pin
PH8
PH9
PH10
PH11
PH12
PI0
PI1
PI2
PI3
PI4
PI5
PI6
PI7
PI8
PI9
PI10
PI11
PI12
PI13
PI14
PI15
PJ0
PJ1
PJ2
PJ3
PJ4
PJ5
PJ6
PJ7
PJ8
PJ9
PJ10
PJ11
PJ12
PJ13
PJ14
PJ15
PK0
PK1
PK2
PK3
STM32MP257F-EV1 I/O assignment
Assignment
ETH3.RXD3
ETH1.CLK125
ETH1.TXD2
ETH1.TXD3
ETH1.RXD3
CAM_ENABLE
I2C1.SDA
TOF_INT
IMU_INT1
IMU_INT2
DISP.BLCTRL
-
CAM_RESET
BUTTON.TAMP
DISP.TE
-
GPIO.SDMMC3_D3
FDCAN3.RX
DISP.LVDS_INT
HDMI_I2S2.WS
-
PCIE.CLKREQN
GPIO.GPIO7
GPIO.SAI2_SDB
GPIO.SAI2_FSA
GPIO.TIM8_CH4
GPIO.TIM8_CH1
LED3
LED4
PCIE.RSTN
ETH1.NRST
-
GPIO.SAI2_SCKA
GPIO.SAI2_SDA
FDCAN1.STBY
FDCAN3.TX
FDCAN3.STBY
HDMI_CEC
HDMI_I2S2_SDO
-
-
