6.6 Clock sources
6.6.1 LSE clock reference
The LSE clock reference on the STM32MP257FAI3 microprocessor is provided by the external crystal X2:
• 32.768 kHz crystal
6.6.2 HSE clock reference
The HSE clock reference on the STM32MP257FAI3 microprocessor is provided by the external crystal X4:
• 40 MHz crystal
6.7 Reset sources
The reset signal of STM32MP257F-EV1 is active LOW. The internal pull‑up of the STM32MP2 forces the NRST
signal to a high level.
The sources of reset are:
• The reset button B1 (black button)
• STPMIC25APQR
• The embedded STLINK-V3EC
• STM32MP257FAI3
6.8 Boot options
At startup, the boot pins select the boot source used by the internal bootROM.
configurations of the boot pins.
Boot 3
0
0
0
0
0
0
1
1
Note: For the complete table, refer to the STM32MP257 datasheet.
UM3359 - Rev 2
Table 5.
Boot 2 Boot 1 Boot 0
0 0 0
0 0 1
0 1 0
0 1 1
1 0 0
1 1 1
0 0 0
0 1 1
Boot mode pin simplified table
Boot mode A35
Forced USB boot for flash
programming
SD card on SDMMC1
eMMC on SDMMC2
Development boot
QSPI
-
-
-
UM3359
Hardware layout and configuration
Table 5 describes the
Boot mode M33
Forced USB boot for flash
programming
-
-
-
SD card on SDMMC1
eMMC on SDMMC2
QSPI
