Ball
F17
V12
W11
V10
W10
Y10
Y9
AB8
T9
AA8
AA7
AA6
Y6
K3
L4
H1
L7
W7
W6
Y4
W4
AA4
L1
H2
K4
L5
G3
H3
J4
J3
K5
G4
H4
V3
V2
V13
W14
AB15
AA15
AA14
T13
UM3359 - Rev 2
Pin
PE15
PF0
PF1
PF2
PF3
PF4
PF5
PF6
PF7
PF8
PF9
PF10
PF11
PF12
PF13
PF14
PF15
PG0
PG1
PG2
PG3
PG4
PG5
PG6
PG7
PG8
PG9
PG10
PG11
PG12
PG13
PG14
PG15
OSC_IN
OSC_OUT
PH2
PH3
PH4
PH5
PH6
PH7
STM32MP257F-EV1 I/O assignment
Assignment
eMMC.SDMMC2_CMD
ETH1.MDC
ETH1.RXD0
ETH1.MDIO
ETH1.CLK
ETH2.CLK
ETH2.MDINT
ETH2.RX_CLK
ETH2.GTX_CLK
ETH2.CLK125
ETH2.RXD2
VBUS_DIV
MCO1
-
GPIO.USART6_TX
GPIO.USART6_RX
GPIO.USART6_CTS
ETH2.RXD0
TCPP_INTN
TCPP_EN
-
-
GPIO.USART6_RTS
ETH2.NRST
TOF_LPn
BUTTON.User2
UART5_TX
UART5_RX
FDCAN1.TX
FDCAN1.RX
I2C1.SCL
DISP.RESET
DISP.LED_EN
HSE_IN
HSE_OUT
ETH3.GTX_CLK
ETH3.TXD3
LED1
PCIE.NWAKE
ETH3.TXD2
ETH3.RXD2
