8 STM32MP257F-EV1 I/O assignment
Ball
Y2
V15
W13
T14
Y15
Y13
V14
Y14
W15
T12
U13
W12
U12
Y12
U10
T10
C11
D11
C10
E10
D10
B11
C12
D12
G11
A12
A11
B12
B20
D19
C20
AB4
AA12
V11
Y11
W9
V9
U9
UM3359 - Rev 2
Table 32. STM32MP257 Evaluation board I/O assignment
Pin
PA0
PA1
PA2
PA3
PA4
PA5
PA6
PA7
PA8
PA9
PA10
PA11
PA12
PA13
PA14
PA15
PB0
PB1
PB2
PB3
PB4
PB5
PB6
PB7
PB8
PB9
PB10
PB11
PB12
PB13
PB14
PB15
PC0
PC1
PC2
PC3
PC4
PC5
STM32MP257F-EV1 I/O assignment
Assignment
PA0_WKUP
ETH3.MDINT
ETH3.RX_CTL
ETH3.TX_CTL
USART2_TX
ETH3.RX_CLK
ETH3.TXD0
ETH3.TXD1
USART2_RX
ETH3.RXD0
ETH3.RXD1
ETH1.RX_CTL
ETH1.MDINT
ETH1.TX_CTL
ETH1.RX_CLK
ETH1.TXD0
HDMI_I2S2.CK
GPIO.SPI3_NSS
-
-
I2C2.SDA
I2C2.SCL
-
GPIO.SPI3_SCK
GPIO.SPI3_MOSI
GPIO.TIM10_CH1
GPIO.SPI3_MISO
GPIO.TIM12_CH2
GPIO.SDMMC3_D2
GPIO.SDMMC3_CK
GPIO.SDMMC3_D0
mkB.PWM
ETH1.GTX_CLK
ETH1.TXD1
ETH1.RXD1
ETH2.RX_CTL
ETH2.TX_CTL
ETH2.MDIO
