Table 4-3 NEC Versa 6200MX Series Field-Replaceable Parts*
ITEM
1. Battery Compartment Cover (Cap)
2. Bottom Base Assembly
4. PC Card Holder
11. Bridge Battery
12. Speaker with Cable (also called Buzzer)
14. TV Compartment Cover (Cap)
15. CMOS Battery
16. IRDA FPC Assembly
17. HDD Compartment Cover (Cap)
19. I/O Board, (G8YAP)
20. CPU Board, 166 MHz (G8YALA)
22. Graph Board (G8YAN)
23. LCD Indicator
25. Sound Board Assembly (G8YAQ)
27. Fan
29. VersaGlide Assembly
30. Speaker Assembly
33. Speaker Cover (left)
35. Speaker Cover (right)
37. Keyboard - U.S.
U.K. (128WC-012)
GERM (128WC-012)
AUSTRALIA (128WC-012)
Europe (128WC-012)
Items Not Shown on IPB Drawing
AC Power Cord-U.S.
AC Power Cord-GERM
AC Power Cord-U.K.
AC Power Cord-AUSTRALIA
AC Adapter
Cable 13.3' XGA Assembly
CD-ROM (10X) Assembly
PART NUMBER
136-240832-103A
136-240825-103A
136-628883-101A
804-021205-003A
802-870018-008A
136-240910-101A
804-021107-003A
808-876328-001A
136-240831-103A
158-026241-000C
158-026239-001C
158-026240-000C
808-872191-005A
158-026242-001B
808-876290-002A
808-874649-201A
808-876317-002A
136-628885-101A
136-628886-101A
808-897300-001A
808-897300-002A
808-897300-003A
808-897300-004A
808-897300-101A
808-741299-001A
808-741300-001A
808-741301-001A
808-741303-001A
808-891864-003A
808-742928-001C
OP-220-62005
