ITEM
System Board
CPU
Clock Speed
CPU Bus Speed
Flash ROM
Connector Support
Memory
System Memory
Optional
Video RAM
Video Interface (VGA)
LCD
Table 1-7 Specifications
SPECIFICATION
Intel Pentium 166 MHz with 16 KB L1 cache and built-in
numeric coprocessor
166 MHz
66 MHz
256 KB: 28F020
Parallel —1 port, 25-pin D-sub
Serial — 1 port, 9-pin D-sub
Infrared — 1 on front of system
VGA — 1 port, 15-pin high-density D-sub
External Keyboard/External Mouse — 1 port, PS/2, 6-pin
MiniDin; exclusionary use or both supported with optional
Y-adapter
Expansion — 1 port, for optional NEC Docking Station 6000
Plus, optional PortBar 6000, or optional FDD Connector Kit.
Mono MIC IN — 1 port, 3-pin, Mini Pin Jack
Stereo Headphones — 1 port, 3-pin, Mini Pin Jack, .5 watts per
channel
Stereo Line-In — 1 port, 3-pin, Mini Pin Jack
Stereo Line-Out — 1 port, 3-pin, Mini Pin Jack
TV Out — 1 port; RCA Jack
DC In — 1 port, for AC adapter cable
32 MB high-speed EDO access, 70 ns
Two DIMM sockets (for base and expansion memory) under
the keyboard, available for one additional SODIMM.
Expandable in 16-MB, 32-MB, 64-MB increments
Maximum 128-MB (by swapping base RAM to 64-MB and
adding a 64-MB expansion DIMM)
2-MB
13.3-inch high resolution active matrix thin Film Transistor
(TFT) Extended Graphics Array (XGA) color display, 1024 x
768 pixels, 0.264 mm dot pitch, 256,000 colors
