Status Icons

The following list defines the status icons displayed in the system status bar.
T
Suspend — appears when the system is in Suspend mode. Suspend mode con-
serves system power by shutting down devices in the system while retaining data
and system status.
T
Power Management — shows the current power management mode in use, in-
cluding Off, Custom, High Performance or Longest Life.
T
Diskette Drive — appears when the NEC Versa writes data to or retrieves data
from a diskette.
T
Hard Disk — shows when the NEC Versa writes data to or retrieves data from
the hard disk.
T
Caps Lock — appears when Caps Lock is in effect.
T
Scroll Lock — shows that Scroll Lock is in effect.
T
Num Lock — appears when Num Lock is in effect. Num Lock lets the user enter
numbers for calculations via the numeric keypad.
T
Battery Status — displays the percentage of battery power available.
Battery 1 appears when you have the main battery installed in the battery bay.
Battery 2 appears when you have an optional battery installed in the
VersaBay II.
Figure 1-4 System Status Bar
Technical Information 1-5
