12 Field Service Guidelines

Memory Upgrade

The NEC Versa 6200MX comes standard with 32 megabytes (MB) of random access
memory (RAM). You can increase system memory to a maximum of 128 MB. The RAM
combinations possible are 32, 48, 64, 96 and 128 MB depending on which two of the listed
dual inline memory modules (DIMM) are used.
T
16-MB memory module
T
32-MB memory module
T
64-MB memory module
The following table shows the memory expansion possibilities.
BASE MEMORY
32 MB
32 MB
32 MB
64 MB*
*
Replacing the provided 32-MB DIMM with a 64-MB DIMM provides optimum memory expansion.
Figure 4-10 Positioning the Keyboard
Table 4-2 System RAM Expansion
EXPANSION MEMORY
16 MB
32 MB
64 MB
64 MB
TOTAL MEMORY
48 MB
64 MB
96 MB
128 MB
