B-4 Video Modes
Mode Memory
Mode Type Org
30 Graph* Pack Pix
31 Graph* Pack Pix
32 Graph* Pack Pix
34 Graph* Pack Pix
38 Graph* Pack Pix
40 Graph* Pack Pix
41 Graph* Pack Pix
42 Graph* Pack Pix
43 Graph* Pack Pix
44 Graph* Pack Pix
45 Graph* Pack Pix
50 Graph* Pack Pix
52 Graph* Pack Pix
6A Graph Planar
64 Graph Planar
68 Graph Planar
70 Graph Pack Pix
71 Graph Pack Pix
72 Graph Pack Pix
74 Graph Pack Pix
78 Graph Pack Pix
*
Linear Addressing Mode.
NOTE: 200-, 350-, and 400-line modes are converted to 768 lines by the BIOS.
200-line mode (0, 1, 2, 3, 4, 5, 6, D, E, 10, 13) is converted to 400-line mode with double scan.
Table B-6 Extended Video Mode
Pixel Display
Resolution Color Fonts
640x480 256 80x30
640x400 256 80x25
800x600 256 100x37
1024x768 256 128x48
1280x1024 256 160x64
640x480 32K 80x30
640x480 64K 80x30
800x600 32K 100x37
800x600 64K 100x37
1024x768 32K 128x48
1024x768 64K 128x48
640x480 16M 80x30
800x600 16M 100x37
800x600 16 100x37
1024x768 16 128x48
1280x1024 16 160x64
640x480 256 80x30
640x400 256 80x25
800x600 256 100x37
1024x768 256 128x48
1280x1024 256 160x64
Dot Horiz.
Font Clock Freq.
Size (MHz) (KHz)
8x16 25.175 31.5
31.5 37.5
36 43.3
8x16 25.175 31.5
8x16 40 37.9
49.5 46.9
56.25 53.7
8x16 65 48.4
78.75 60
94. 68.7
8x16 78.75 47
8x16 25.175 31.5
31.5 37.5
36 43.3
8x16 25.175 31.5
31.5 37.5
36 43.3
8x16 40 37.9
49.5 46.9
56.25 53.7
8x16 40 37.9
49.5 46.9
56.25 53.7
8x16 65 48.4
78.75 60
8x16 65 48.4
78.75 60
8x16 25.175 31.5
31.5 37.5
36 43.3
8x16 40 37.9
8x16 40 37.9
49.5 46.9
56.25 53.7
8x16 65 48.4
78.75 60
8x16 78.75 47
8x16 25.175 31.5
31.5 37.5
36 43.3
8x16 25.175 31.5
8x16 40 37.9
49.5 46.9
56.25 53.7
8x16 65 48.4
78.75 60
8x16 78.75 47
Vert. Video
Freq. Memory
(Hz) (KB)
60 512
75
85
70 256
60 512
75
85
60 1024
75
85
43(I) 1280
60 1024
75
85
60 1024
75
85
60 512
75
85
60 512
75
85
60 1536
75
60 1536
75
60 1024
75
85
60 1536
60 256
75
85
60 512
75
43(I) 768
60 512
75
85
70 256
60 512
75
85
60 1024
75
43(I) 768
