Travel Motor Oil

• Always park machine on a level surface and block tracks with chocks when
working under machine.
• Dispose of the drained oil properly, according to the national and local regula-
tions.
NOTE
• Oil to use and amount: see Page 57.
36A3M-0507-040E
36A3M-0507-050E
Maintenance
Drain Plug
Drain Port
Check Port Plug
10. Adjust the track tension.
11. Remove grease pump, install valve cover,
and lower the machine.
1. Park the machine on a level ground. Park it
so that the drain plug of the travel moror is at
the bottom.
2. Have an appropriate oil drain pan.
3. Remove the motor drain plug to drain oil.
4. Drive the machine so that the drain plug
higher than the check port plug.
6. Remove the check port plug.
7. Fill lubricant into the drain port until oil comes
out of the check port.
8. Reinstall the drain and check plugs.
-75-
