Hoisting and Towing

Hoisting

• Hoisting requires qualifications. Check with your local authority for necessary
qualifications and licenses for hoisting.
• Use hoisting sling of sufficient strength. Always use the slings of the same
length when more than one is used.
• Beware of the shift in the center of gravity and balance of the machine when
hoisting.
• Always unload the machine before hoisting.
3670M-0702-013E
3670M-0702-023E
Transporting
Lift Hooks
One-Side Dump Model
Lift Hooks
Turn and Dump Model
1. Raise the bucket body (vessel) and lock it
with the bucket body safety prop. (Page 43)
2. Hitch the wire rope to the lifting hooks (3
places) attached to the frame and lift the
machine. At this time, adjust the wire rope
length so that the machine will be horizontal.
3. Use the slinging implements (wire rope,
chain, etc.) should have sufficient strength.
