either vertical or horizontal position. Remember that wiring access is
likely the most important consideration.
PERSONAL INJURY HAZARD
Failure to follow this caution may result in personal injury.
To prevent possible damage to the Damper Control Module, DO
NOT mount on plenum, ductwork, or flush against furnace or
fan coil.
4.5. Decorative Trim Plate
Sold separately, a paint-able decorative trim plate is available to hide any
marks/screw holes left from the previous thermostat. The trim plate is
installed between the backplate and the wall. Align the trim plate around
the backplate, and snap on the system control.
NOTE: Once the Evolution Connex Control is secured to wall with the
backplate assembly (snapped together), care must be taken not to bend or
break the interlocking tabs when removing.
4.5.1. Mounting
First become familiar with all plastic assembly pieces shown on the
following page. The Evolution Connex Control will snap together with
the standard backplate supplied with the wall control. Attach backplate
using only a small hole in the wall allowing a four wire connection to
pass through. Mount the front assembly to the standard backplate. The
figure below shows the optional decorative trim plate, described in the
Decorative Trim Plate Section, installed with the standard backplate. The
decorative trim plate is captured between the backplate and the system
CAUTION
!
16
