Page 1: Table Of Contents
........ Fig. 1 - Carrier Côrt Thermostat Cool to Dehumidify .
Page 2: Overview
You’ll also receive customized tips to help you save even more. Based on a 2012 third - party study comparing Carrier Côr™ technology to the estimated cost of a non - programmable thermostat set to 72° F at all times. Your Carrier Côr Thermostat Features Your thermostat has an easy- to- read color touch screen that displays all the information you need to set and manage your home’s heating and...
Page 3: Installation
When using your tablet or laptop, use your web browser to go to www.mycorhome.com and click on “Login” at the top right of the page. Touch the register button next to the image of your thermostat. When using your smartphone, download the free Carrier Côr thermostat app from your device’s app store. Open the app then touch the Register button.
Page 4: Thermostat Basics
THERMOSTAT BASICS Home Screen A14581 A. Fan mode – change your fan mode B. Current temperature – your home’s current temperature  C. Touch- N- Go Feature – quickly manage your home’s comfort and energy usage when you’re on the go D.
Page 5: Touch Screen
Touch Screen Your thermostat has a touch screen, similar to that used in smartphones and tablets. Touch items to select or activate them. For menus with a >, touch to display additional options or submenus. Menu Navigation: S Touch Back to return to the previous screen. S Touch Done to return to the Home Screen.
Page 6: Using Your Thermostat
USING YOUR THERMOSTAT The bright, easy- to- read touch screen on your thermostat makes it simple to review and adjust settings any time you want. Adjusting the Temperature Manual Adjustments You can manually adjust the temperature from the Home Screen by touching the up or down arrows. To adjust your cooling set point, touch “Cool to”, then adjust using the up and down arrows.
Page 7: Selecting System Operation Mode
Use the bottom Touch- N- Go button to select the length of time you wish to stay in that profile or resume your schedule. A150008 NOTE: You adjust your default Touch- N- Go hold time in the Preference menu (Touch Menu > Settings > Preferences). Selecting System Operation Mode The Fan and Mode drop- down menus in the upper right and left corners of the Home Screen allow you to quickly change the operating mode of your system.
Page 8: Fan
The Fan menu displays the current fan setting. Depending on your system, one or more of the following options are shown: S On: Fan runs continuously, regardless of the scheduled programming. The fan will also run if the System Mode is Off. S Auto: Fan runs when the system is actively heating or cooling your home, or to satisfy the Air Circulation setting.
Page 9 Adjusting Comfort Profiles Your thermostat organizes your temperature and fan settings into different comfort profiles. These profiles are used in your weekly schedule, if you make a change with Touch- N- Go. A14588 By default, your thermostat includes four configurable activity periods: S Away: Settings for when you are not at home.
Page 10: Setting Your Weekly Schedule
Setting Your Weekly Schedule Your schedule can have a large impact on your heating and cooling system’s energy use. But your comfort needs change depending on the time of day, day of the week, and if you are at home or away. To help you save on energy while keeping you comfortable, the Côr thermostat is simple and intuitive to program.
Page 11 5. Uncheck any unneeded times 6. Select the Next button 7. Schedule additional days of the week 8. Select the Next button 9. Select the Save button Edit Your Schedule You can use the Guided Scheduling feature to edit your schedule at any time or you can edit your schedule manually. Manually editing your schedule will also allow you to schedule any custom Comfort Profiles you’ve created.
Page 12 3. To edit the temperature settings for the Comfort Profile, select the Comfort Profile and adjust your temperature and fan settings then select Update. 4. To delete a scheduled period, select the icon, touch the X, then confirm by selecting Delete. 5.
Page 13: Going On Vacation
Going on Vacation Your thermostat’s Vacation feature helps you conserve energy while you are away for extended periods of time. It also helps ensure your home is comfortable when you return. A vacation event includes a start date and time, as well as the end date and time. You can enter any number of vacations. Using the Vacation feature overrides your programmed schedule, so you can leave your regular Schedule as- is when you go away for a special or unscheduled trip.
Page 14: Smart Home / Away Setting
On Web Portal: A150016 1. Select Schedule tile. 2. Select New Vacation 3. Enter the depart and return date and times 4. Select Heat and Cool. 5. Enable or disable heat and cool during the period as required. 6. Select the set points for heat and/or cool. 7.
Page 15: Humidifier
On the Web Portal: A170288 1. Select the My System tile. 2. Select Smart Home / Away 3. Select Enable or Disable Humidifier The Humidifier menu enables or disables a whole home humidifier, if installed: S On: Run the humidifier to increase the humidity to the configured set point. S Off: Do not operate the humidifier.
Page 16: Dehumidifier
Dehumidifier The Dehumidifier menu enables or disables a whole home dehumidifier, if installed: S On: Run the dehumidifier to reduce the humidity to the configured set point. S Off: Do not operate the dehumidifier. On Thermostat and Smartphone App: Touch Menu > System > Dehumidifier On the Web Portal: 1.
Page 17: Caring For Your Thermostat
S Software version S Contact information for your HVAC contractor S Contact information for Carrier Customer support This information is useful when troubleshooting network issues or contacting Carrier technical support. On the Thermostat and Smartphone App: Touch Menu > Service On the Web Portal: Select About tile.
Page 18: Reminders & Alerts
REMINDERS & ALERTS The Reminders and Alerts list displays the reminders and alerts that help you know when to perform periodic maintenance or if there is a potential issue with your heating and cooling system. If you have registered your thermostat, alerts and reminders can also be sent via email, to your smartphone app, and web portal. Reminders and alerts will display along with your HVAC Contractors contract information, if available.
Page 19: Viewing Reminder Status
Viewing Reminder Status You can quickly view the status of your reminders on the thermostat using the Reminder Status screen. The reminder status is displayed as a percentage of time used based on your reminder settings. On the Thermostat: S Touch Menu > Alerts > Reminder Status Configuring Reminders &...
Page 20 S Enable/Disable: Configures whether or not to generate an alert. S A temperature range of 35 to 68 °F (1.5 to 20 °C). High Temperature Alert When enabled, an alert will be sent if your home’s temperature reaches this setting. You can adjust: S Enable/Disable:Configures whether or not to generate an alert.
Page 21: Customizing Your Settings
CUSTOMIZING YOUR SETTINGS You can further customize the operation and display of your thermostat to suit your personal preferences. NOTE: System settings are only configurable from the thermostat itself, not the Smartphone App. Some settings, where indicated, are also configurable from your Web Portal. Smart Setback Smart Setback helps take the guesswork out of balancing your comfort and energy savings.
Page 22: Temperature Display
On Thermostat: To adjust the time format: 1. Touch Menu > Settings > Time & Location 2. Touch Set time display format 3. Touch 12 hr or 24 hr. Touch Save. On Web Portal: 1. Select Settings tile. 2. Select Time. 3.
Page 23: Screen Brightness
On the Web Portal: 1. Select Settings tile. 2. Select Preferences. 3. Select Thermostat name 4. Select an existing name from the list or choose Custom Name and enter your own). 5. Select Update Name Screen Brightness You can customize the brightness of your thermostat’s screen. The brightness for both the active and standby screens can be configured independently.
Page 24: Access Control
Hold until a specific time Always ask you Access Control You can prevent people from making changes your thermostat’s set points, schedule, vacation, or system settings by configuring a 4- digit security code. If enabled, the security code will be required to access and change these settings. On Thermostat: 1.
Page 25: Advanced Wi- Fi
S View Log: Displays log file information about Wi- Fi operation. S Ping Gateway: Checks to see if the network gateway is responding. S Ping Carrier.com: Checks to see if the Carrier servers are responding. S Ping Address: Checks to see if the entered IP address is responding.
Page 26: Managing Your Account
MANAGING YOUR ACCOUNT Your thermostat is designed to securely communicate over the Internet with Carrier servers in order to obtain precise weather information and provide your own personalized web portal. Registering To access all the features of your thermostat, register at www.mycorhome.com. After registration, you can control your thermostat from your smartphone, tablet or desktop, and access free online energy management tools.
Page 27: Approvals
1- 800- CARRIER Catalog No: OM- TPWEM- 02 Copyright 2017 Carrier Corp. S 7310 W. Morris St. S Indianapolis, IN 46231 Edition Date:12/17 Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
