2.1. Technical Specifications UR3e
Robot type
Robot weight
Maximum payload
Reach
Joint ranges
Speed
System update frequency
Force Torque sensor accuracy
Pose repeatability
Footprint
Degrees of freedom
Control Box size (W × H × D)
Control Box I/O ports
Tool I/O ports
Tool Communication
Tool I/O power supply & voltage
Control Box I/O power supply
Communication
Programming
Noise
IP classification
Cleanroom classification
Power consumption (average)
Power consumption
Short-Circuit Current Rating (SCCR)
Collaboration operation
Materials
Ambient temperature range
Control Box power source
TP cable: Teach Pendant to Control Box
Robot Cable: Robot Arm to Control Box
(options)
UR3e PolyScope X
UR3e
11.1 kg / 24.5 lb
3 kg / 6.6 lb
500 mm / 19.7 in
Unlimited rotation of tool flange, ± 360 ° for all other joints
± 360 ° for all joints
All wrist joints: Max 360 °/s.
Other joints: Max 180 °/s .
Tool: Approx. 1 m/s / Approx. 39.4 in/s.
500 Hz
3.5 N
± 0.03 mm / ± 0.0011 in (1.1 mils)per ISO 9283
Ø128 mm / 5.0 in
6 rotating joints
460 mm × 449 mm × 254 mm / 18.2 in × 17.6 in × 10 in
16 digital in, 16 digital out, 2 analog in, 2 analog out
2 digital in, 2 digital out, 2 analog in
RS
12 V/24 V 600 mA
24 V 2 A in Control Box
TCP/IP 1000 Mbit: IEEE 802.3ab, 1000BASE-T Ethernet
socket, MODBUS TCP & EtherNet/IP Adapter, Profinet
PolyScope graphical user interface on 12" touchscreen
Robot Arm: Less than 60dB(A) Control Box: Less than
50dB(A)
Robot Arm: Less than 65dB(A) Control Box: Less than
50dB(A)
IP54
Robot Arm: ISO Class 7, Control Box: ISO Class 6
300 W
Approx. 150 W using a typical program
200A
17 advanced safety functions. In compliance with: EN ISO
13849-1, PLd, Cat.3 and EN ISO 10218-1
Aluminium, PC/ASA plastic
0-50 °C. At ambient temperatures above 35°C, the robot
may operate at reduced speed and performance.
100-240 VAC, 47-440 Hz
4.5 m / 177 in
Standard (PVC) 6 m/236 in x 13.4 mm
Standard (PVC) 12 m/472.4 in x 13.4 mm
Hiflex (PUR) 6 m/236 in x 12.1 mm
Hiflex (PUR) 12 m/472.4 in x 12.1 mm
