Cisco C1131X-8PLTEPW Series Hardware Installation Manual page 90

Configuring a Pluggable Interface Module
same click and let it go, the SIM connector should eject part way out of the connector. The SIM card can
then be grabbed and removed).
Secure the Micro-SIM cover with a screw, use a number 1 Philips screw driver to secure the screw on the
Micro-SIM cover. The recommended torque is 2.8 - 3.8 inch LBF.
Note
4. You have now successfully inserted the Micro-SIM cards into the LTE pluggable module. The marking
on the Mirco-SIM door should align with Micro-SIM 0 on the pluggable module with the arrow pointing
upward.
Figure 77: Insert the Micro-SIM Cards
Configuring a Pluggable Interface Module
To insert the antenna in the Pluggable Interface Module, perform the following steps:
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
84
We recommend using industrial-grade SIM cards.
Install and Upgrade Internal Modules and Field Replaceable Units
