Chassis Views
1 Non-illuminated Cisco logo
Figure 17: C1121(X)-8PLTEPW I/O View
1 Reset button
3 4-pin power connector
5 Wi-Fi status
7 GE WAN 0/0/0 -RJ45
9 Micro-USB console
11 Pluggable
13 Grounding
Figure 18: C1127X-8PLTEP Bezel View
1 Non-illuminated Cisco logo
Figure 19: C1127X-8PLTEP IO Panel View
1 Reset button
3 4-pin power connector
5 RJ-45
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
12
Overview of Cisco 1000 Series Integrated Services Routers
2 Power switch
4 Ethernet switch
6 GE 0/0/1
8 GE WAN 0/0/0 -SFP
10 USB 3.0
12 Kensington lock slot
2 Power switch
4 Ethernet switch
6 GE WAN 0/0/0 -RJ45
