Install and Upgrade Internal Modules and Field
Replaceable Units
The Cisco 1000 Series Integrated Services Routers have internal modules and field-replaceable units (FRUs)
that can be quickly and easily removed and replaced without having to send the entire router for repair.
This section describes how to install the internal modules and FRUs in the Cisco 1000 Series Integrated
Services Routers. The information is contained in the following sections:
•
•
•
•
•
•
Replace the Chassis Covers for C111X and C1111x
To access the internal modules on the router, you must first remove the chassis cover. See the instructions
below on how to remove and later replace the chassis cover on the routers.
Warning
Cisco 1000 Series Integrated Services Routers have removable covers. Do not run the routers with the cover
off. Doing so can cause the router to overheat very quickly.
Use a number-2 Phillips screw driver to perform the following tasks.
Replace the Chassis Covers for C111X and C1111x, on page 71
External Modules, on page 74
Install and Remove Small Form Pluggable Modules, on page 75
Install a Pluggable Interface Module, on page 76
Installing a SIM Card on C111X, C1109-2PX, C1109-4P, on page 100
Installing a Nano-SIM Card into a Nano-To-Micro-SIM Adapter, on page 103
Only trained and qualified personnel should be allowed to install, replace or service this equipment. Statement
1030
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
