The following table summarizes the LED indicators that are located in the bezel or chassis of the C111x series.
Table 5: LED Indicators for C111x
Port
Cisco logo
Status
(System status)
VPN OK
Wi-Fi
GE 0/0/1 RJ45 LED
GE 0/0/0 SFP LED
Console LED
LED Color
Blue
Green and Amber
Green
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
6 GE 0/0/1 SFP LED
8 GE 0/0/0 RJ45 LED
10 USB LED
Description Control Source
Illuminated Cisco logo. Bezel side
Indicates that router is
powered on.
Steady green - System is Bezel side. All models.
operating normally.
Off—System is not out of
reset mode or BIOS image
is not loadable.
Blinking Amber —
BIOS/ROMmon is
booting.
Steady Amber —
BIOS/ROMmon has
completed booting, and
the system is at the
ROMmon prompt or
booting the platform
software.
Off— No tunnel. Bezel side
Steady On— At least one
tunnel is up.
