LED Indicators
Figure 27: Cisco 1121-4Px LED Indicators
1 VPN
3 Status
5 GE 0/0/0 RJ45 LED
7 GE 0/0/0 RJ45 LED
9 USB LED
Figure 28: Cisco 1121-4PLTEP LED Indicators
1 VPN
3 Status
5 GE 0/0/0 RJ45 LED
7 GE 0/0/0 RJ45 LED
9 USB LED
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
16
Overview of Cisco 1000 Series Integrated Services Routers
2 PoE LED
4 Ethernet switch ports 0-3
6 GE 0/0/1 LED
8 Micro USB console LED
2 PoE LED
4 Ethernet switch ports 0-3
6 GE 0/0/1 LED
8 Micro USB console LED
