Overview of Cisco 1000 Series Integrated Services Routers
Figure 29: Cisco 11x1(X)-8P/ C11x1(X)-8PLTEP LED Indicators
1
3
5
7
9
Figure 30: C1121(X)-8PLTEPWx LED Indicators
1
3
5
7
9
VPN
Status
GE 0/0/0 RJ45 LED
GE 0/0/0 RJ45 LED
USB LED
VPN
Status
Wi-Fi
GE 0/0/1 LED
USB LED
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
2 PoE LED
4 Ethernet switch ports 0-7 (0, 2, 4, 6 at the top
and 1, 3, 5, 7 at the bottom)
6 GE 0/0/1 LED
8 Micro USB console LED
2 PoE LED
4 Ethernet Switch Ports 0-7 (0, 2, 4, 6 at the top
and 1, 3, 5, 7 at the bottom)
6 GE 0/0/0 RJ45 LED
8 GE 0/0/0 SFP LED
10 Micro USB console LED
LED Indicators
