LED Indicators
Figure 31: Cisco 1126(X)-8PLTEP/ C1127(X)-8PxLTEP LED Indicators
1 VPN
3 Status
5 GE 0/0/0 RJ45 LED
7 GE 0/0/0 SFP LED
9 CD LED
Figure 32: C1131(X)-8PW LED Indicators
Figure 33: C1131-8PW LED Indicators
Table 4: C1131(X)-8PW/C1131-8PW LED Indicators
1 VPN
3 Status
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
18
Overview of Cisco 1000 Series Integrated Services Routers
2 PoE LED
4 Ethernet Switch Ports 0-7 (0, 2, 4, 6 at the top
and 1, 3, 5, 7 at the bottom)
6 USB5 LED
8 Micro USB console LED
2 PoE LED
4 Ethernet switch ports 0-7 (0, 2, 4, 6 at the top
and 1, 3, 5, 7 at the bottom)
