Install and Connect the Router
Attach the C1121/C1161 Top Plate (C1120-TOP-PLATE=) on Desktop
Figure 41: Aligning the securing holes of top plate to C1121/C1161
1
Align securing holes
Step 5
Use Phillips 2 screwdriver to secure screws to 6-8 in-lbs.
Example:
Hardware Installation Guide for the Cisco 1000 Series Integrated Services Router
41
